Access Control/Products/Readers/Proximity 125kHz
hfslwaaescda2

HFS-LWA Prox 125kHz Reader Mullion

Partcode:
  • V54547-Z101-A100
The HFS-TKWA-AES/CDA2 Card Reader without a keypad, boasts a robust yet stylish design. Developed to withstand challenging external environments but at the same time remains visually appealing in its contemporary silver aluminium housing. It connects seamlessly with the feature rich SPC system via the SPCA210 door expander providing an excellent user experience.
Technical dataDocumentationSoftwareCertificatesImport & Export

  • Interfaces

    Wiegand 37 Bit

  • Cable length

    4m

  • Operating voltage

    10 ~ 14VDC

  • Operating current

    22 mA bei 12 VDC

  • Quiescent current

    6 mA bei 12 VDC

  • Mounting

    Flat surface wall mount

  • Colour

    Eloxiert Silber

  • Weight

    0.320 kg

  • Dimensions (W x H x D)

    50 x 120 x 25 (mm)

  • Material

    Aluminium

  • Operating temperature

    -15 ~ +65 °C

  • Card read distance

    2 cm

  • Environmental class

    IV
