sr35ia32

SR35iA/32 Aperio Controller, 32 door

Partcode:
  • V54502-C101-A300
The SR35iA Aperio is the controller for the Aperio readers in an Omnis system. Together with the Entro software the Aperio readers can be configured (time schedules, access groups, security levels…). Communication between Omnis and SR35iA Aperio is done over TCP/IP network using BAPSI protocol with 128-bits encryption. Communication between SR35iA Aperio and Aprio Hub AH30 via RS485 interface. Up to 15 Aperio hub’s AH30 can be connected to same RS485 interface. The SR35iA Aperio comes in three different sizes (reader capacities)‚ 8 readers SR35iA/8, 16 readers SR35iA/16 and 32 readers SR35iA/32. Communication between point of configuration (e.g. Entro PC-client) and SR35iA can be established over RS232 or TCP/IP networks.
Technical dataDocumentationSoftwareCertificatesImport & Export

  • Dimensions (W x H x D)

    248 x 182 x 66 (mm)

  • Weight

    0.98 kg

  • Operating temperature

    0 till +50 °C

  • Colour

    Vit

  • Housing

    Plastkapsling för väggmontage

  • Interfaces

    Inbyggd 2-port switch med 2 st RJ45 10/100Mbit kontakter för Ethernet. RS485 global för ihopkoppling av upp till 16 st SR35iA undercentraler. RS485 lokal för anslutning av Aperio AH30 (upp till 15 st AH30 stöds per SR35i/A)

  • Operating voltage

    8-40 VDC, 8-30 VAC 2,3 Watt

  • Door capacity

    32 läsare

  • Environment

    Enbart inomhus
