Approval

EN grade 2 (pending)

Current consumption

max. 44mA

Detection characteristics / range

7m or 15m

Dimensions (W x H x D)

114 x 63 x 40mm

EOL resistor

4K7,4K7 or user selectable Dual EOL values

Horizontal angle of view

100°

Housing material

ABS

Housing protection

IP 3X

LED Indicators

green, yellow, blue

Mounting

2m to 2.2m

Operation temperature

-10°C to +55°C

Optical system

LODIFF Fresnel Lens Technology

Pet immunity

Yes, up to 15kg

Power supply

9-15 VDC

Relative humidity

< 93% without condensation

Tamper switch

Front and Back Tampers

Weight

108g (including packaging)
